Adding Structural Columns inside Architectural Columns

To add structural columns inside architectural columns
1 Make sure the Structural Column command is still active. Click
2 Either select individual architectural columns or drag a pick box over architectural columns in
760 | Chapter 12 Working with Structural Components
the Options Bar.
the view to select multiple columns.
Selecting a single architectural column
Selecting multiple architectural
columns
The structural columns snap to the centers of the architectural columns. For more information
about creating a pick box, see
RELATED You can control how a column family displays within a project plan view. In the Family
Editor, select "Show family pre-cut in plan views" if you want the column display to remain consistent
despite the cut plan for that project plan view. For more information, see
Displays in Plan View on page 427.
Selecting Elements on page 269.
(Architecural Column) on
Specifying How a Column
