Name
Identity Data
Name
Design Option
Extents
Scope Box

Reference Planes

Use the Reference Plane command to draw reference planes to use as a guideline in your design. Reference
planes are an integral part of family creation. See
in each new plan view that you create for a project. See

Adding Reference Planes

1 Click Drafting menu
2 Place the cursor in the drawing area.
3 Draw the reference planes by dragging the cursor.
4 When you finish the plane (designated by a green, dashed line), click to end the line.
1046 | Chapter 16 Annotating and Detailing
Description
A label for the level. You can assign any label or name you wish to this property.
A read-only field that indicates the design option in which the level lines appear.
The scope box applied to the level. See
Boxes on page 1053.
Family Editor Basics
Datum Extents and Visibility
Ref Plane, or on the Drafting tab of the Design Bar, click Ref Plane.
Controlling Visibility of Datums Using Scope
on page 341. Reference planes appear
on page 1048.
