4 Click the color value to set the line color.
5 Select a line pattern.
6 Click the button in the Material field to open the Materials dialog. Select a material for the
7 When you are finished, click OK.

Deleting an Object Style

You can delete any user-created object style.
1 Click Settings menu
2 Select the category name to delete.
3 Click Delete.
4 When prompted to confirm the deletion, click Yes.

Renaming an Object Style

You can rename any user-created object style.
1 Click Settings menu
2 Select the category name.
3 Click Rename.
4 In the Rename dialog, enter a new name.
5 Click OK.

Line Styles

Line styles are used to indicate different effects, such as a dashed (------) line for reference planes. When you
install and run Revit Architecture, several line styles are included. Each predefined line style has a name that
describes either the line (for example, Dash dot), or where Revit Architecture uses the line style (for example,
<Sketch> lines). Revit Architecture stores the line styles in the default template.
When you are in the Family Editor, you cannot create new line styles but you can modify line weight, line
color, and line pattern.

Creating a Line Style

NOTE You can only create line styles in the project environment. You can modify line weight, line color, and line
pattern in the Family Editor. See
1 Click Settings menu
2 In the Line Styles dialog, click New, and enter a new name for the line style.
3 Click the value for Line Weight to choose a line weight.
4 Click the value for Line Color to choose a line color.
family category from the Material column. You can override the material for the family by
changing its material type property. For imported geometry, specify a material for the layer.
This is not available for annotation objects.
Object Styles.
Object Styles.
Modifying Line Styles in the Family Editor
Line Styles.
The name displays under Category in the Line Styles dialog.
on page 486.
Deleting an Object Style | 485
