13 Specify justification.
Refer to the description of Justify in
14 Select Excess Length Fill if you selected Beginning, End, or Center for Justify.
Refer to the description of Excess Length Fill in
15 Click OK.

Overriding the Main Baluster Pattern for Stairs

You can override the main baluster pattern and set a specific pattern for stairs.
1 In a plan view, select a railing, and on the Options Bar, click
2 In the Element Properties dialog, click Edit/New.
3 For Baluster Placement, click Edit.
4 In the Edit Baluster Placement dialog, select Use Baluster Per Tread on Stairs.
5 Specify the number of balusters on each tread.
6 Specify the baluster family for the stairs.
7 Click OK.

Baluster Pattern Properties

Following are the Main Pattern display properties for balusters.
Property
Name
Baluster Family
Base
Base offset
Top
Top offset
Dist. from previous
Offset
Break Pattern at
Baluster Pattern Properties
Description
The name of a specific baluster within the pattern.
The style of the baluster or post family. If you select None, no balusters or posts display in
that portion of the pattern.
Specifies where the bottom of the baluster is placed: at the top of the rail, bottom of the
rail, or top of the host. A host can be a level, floor, stair, or ramp.
The negative or positive vertical distance between the bottom of the baluster and the base.
Specifies where the top of the baluster is placed (usually a rail). Values are the same as
Base.
The negative or positive vertical distance between the top of the baluster and the Top.
The distance between the start of the pattern and the first baluster, or for subsequent
balusters, the distance between the previous baluster in the pattern.
The distance to the inside or the outside of the railing path.
The point along a railing segment at which the baluster pattern stops.
Controlling Placement of Balusters and Posts | 685
on page 685.
Baluster Pattern Properties
.
on page 685.
