Brace Instance Properties - Autodesk 24000-000000-9860 - Revit Architecture - PC User Manual

Name
Start Mx
Start My
Start Mz
End Release
End Fx
End Fy
End Fz
End Mx
End My
End Mz
Analyze As
Other
Start Extension Calculation
End Extension Calculation

Brace Instance Properties

The following table lists the default instance properties for a typical brace when not attached to a beam.
Name
Constraints
Reference Level
Construction
Start Extension
836 | Chapter 12 Working with Structural Components
Description
The rotational release at the start end of the brace along the local x-axis.
The rotational release at the start end of the brace along the local y-axis.
The rotational release at the start end of the brace along the local z-axis.
Fixed, Pinned, Bending Moment or User Defined. User Defined allows you to en-
able/disable each of the end release conditions.
The translational release at the end of the brace along the local x-axis.
The translational release at the end of the brace along the local y-axis.
The translational release at the end of the brace along the local z-axis.
The rotational release at the end of the brace along the local x-axis.
The rotational release at the end of the brace along the local y-axis.
The rotational release at the end of the brace along the local z-axis.
Determines whether brace conditions contribute to lateral analysis. Available for use
by external analysis applications. See
Defines the maximum distance of start extension parameter. Set in family parameters.
Defines the maximum distance of end extension parameter. Set in family parameters.
Description
The constraining level.
The dimension between the edge of the start end of the brace and the element
to which it is connected.
