Sample in-place editing of a furniture tag
If the tag contains a multi-parameter label, click the selected tag to open the Change Parameter Values dialog
and modify the associated parameters. See

Multiple Tags for Families

Families can have multiple tags. To load multiple tags for a family, see

Applying a Tag

Before attempting this procedure, load the necessary tags for elements that need a tag. For example, if you
created a furniture tag, load that furniture tag for furniture. See
1 Click Drafting menu
2 If you want the tag to have a leader line, on the Options Bar, select Leader. If the tag has multiple
3 If desired, enter a value for the length of the leader in the text box next to the Leader check
4 To set the orientation of the tag, select Vertical or Horizontal on the Options Bar.
5 Highlight the element to tag, and click to place the tag.

Changing a Tag Instance

1 Select the tag in the drawing area.
2 In the Type Selector, select another tag.

Aligning Tags

You can align tags with other similar tags by dragging them. For example, a room tag can align with another
room tag, and a generic annotation can align with another generic annotation. As you drag a tag, dashed
green lines appear to show when the tag is aligned with another tag:
1066 | Chapter 16 Annotating and Detailing
Tag, or on the Drafting tab of the Design Bar, click Tag. For generic
annotation tags, drag the tag from the Project Browser onto the view.
leader options, enter a value for Number of Leaders.
box.
After you place the tag, you can change its orientation by selecting the tag and pressing SPACEBAR.
NOTE Additional tags must already be loaded.
