Exporting Shared Parameters To A Shared Parameter File; Tagging With Shared Parameters - Autodesk 24000-000000-9860 - Revit Architecture - PC User Manual

parameters are specific to one family. You can also replace one shared parameter with another. See
Types on page 366.

Exporting Shared Parameters to a Shared Parameter File

You can export shared parameters to a new shared parameter file if the old parameter file is deleted, or if
there are shared parameters in a family or a project that are not in the current shared parameter file.
Before you can export them, you must already have added the shared parameters into a Revit Architecture
project file or family file. For more information on adding shared parameters, see
to Families on page 444 and
1 Create or open a shared parameter file.
For more information on creating shared parameter files, see
on page 442.
2 Select a shared parameter in either a family or a project.
3 Click Modify.
4 In the Parameter Properties dialog, click Export.
NOTE The Export command is never enabled if the selected shared parameter is already in the current
shared parameter file.
An informational message appears informing you that the shared parameter will be exported
to the shared parameter file you set up in Step 1.
5 Click OK to complete the export.

Tagging with Shared Parameters

Shared parameters are available for both single- and multi-category tags. You can apply a multi-category tag
to any kind of component, regardless of its category, by applying a filter parameter to a tag.
Creating a Single-Category Tag
1 Click File menu
Open.
The Family Editor opens.
2 Click Drafting menu
3 Click in the drawing area. The Edit Label dialog opens.
4 Click (Add Parameter).
5 In the Parameter Properties dialog, click Select and select the shared parameter to add to the
label.
6 Click OK twice.
The selected parameter displays in the Category Parameters list.
7 Select the shared parameter from the Category Parameters list and click
to label).
Project Parameters on page 447.
New Annotation Symbol, select a template (such as, Door Tag.rft) and click
Label, or click Label on the Design Bar.
Adding Shared Parameters
Setting up Shared Parameter Files
(Add parameters
Shared Parameters | 445
Family
