Add Shared Parameter: You click this button to enter the Parameter Properties dialog to designate
shared parameters. See
Edit Parameter: You click this button to enter the Parameter Properties dialog to edit a selected shared
parameter. See
Delete Parameter: You click this button to delete a selected shared parameter. Labels sharing the
parameter no longer display its information. See
444.
NOTE Deleted shared parameters are removed from all sharing labels. See

Label Parameter Options

The columns in the Label Parameters window display annotation options for the label. The parameter names
are listed in order in the first column.
Spaces: You increase or decrease the spacing between parameters in the label by entering a representative
number of spaces (zero or greater). This option disables if the Break option is selected.
Prefix: You can add a prefix to the parameter value by adding a text string in this option.
Sample Value: You can change how the place holding text appears in the parameter.
Suffix: You can add a suffix to the parameter value by adding a text string in this column.
Break: You force a line break immediately after the parameter by checking this box. Otherwise, the text
wraps within the label boundary.
Wrap between parameters only: You force text wrapping in the label to break at the end of parameters by
checking this box. If not selected, text wraps at the first word reaching the boundary.
Unadjusted label text

Edit Label Unit Formats

If you create a label with a length, area, volume, angle, or number parameter, you can format the appearance
of the parameter.
1 In the Edit Label dialog, choose a length or area parameter, such as Room area.
2 Click
430 | Chapter 8 Creating Your Own Components (Families)
Adding Shared Parameters to Families
Viewing, Moving, and Deleting Shared Parameters
Wrapping label text
The Format dialog appears.
on page 444.
on page 444.
Viewing, Moving, and Deleting Shared Parameters
Shared Label Parameters
on page
on page 429.
Breaking label text
