Name
Description
Assembly Description
Assembly Code
Type Mark
Fire Rating
Cost

Structural Wall Instance Properties

Name
Constraints
Location Line
Base Constraint
Base Offset
Base is Attached
Base Extension Distance
Top Constraint
Unconnected Height
Top Offset
Description
A description of the wall.
A description of the assembly based on the assembly code selection. This is a read-
only value.
A uniformat assembly code selected from a hierarchical list.
A value that designates the particular wall. This value must be unique for each ele-
ment in a project. Revit Architecture warns you when the number is already used,
but allows you to continue using it. You can see the warning using the Review
Warnings command. See Reviewing Warning Messages
The fire rating of the wall.
The pricing of the wall.
Description
Specifies the position of the wall with respect to the line sketched in the project
elevation. For more information, see
562. The wall location line remains the same for that wall, even if the type changes.
Specifies the level from which the wall base is referenced.
Specifies the offset of the base of the wall from its base constraint.
Indicates whether the base of the wall is attached to another component, such
as a slab. This is a read-only value.
Indicates the distance you have moved the base of the layers in a wall. See
Compound Structure on page 748. This parameter is enabled when the layers of
a wall are set to extendable.
The name of the level to which the wall top is set.
If top constraint is unconnected, you may set an unconnected height of the
wall. This value is read-only if there is a top constraint.
Specifies the offset of the top of the wall from its top constraint; enabled only
when the top constraint is set to a level.
on page 1334.
Adding Interior and Exterior Walls
Structural Wall Properties | 847
