Roof Boundary Line Properties - Autodesk 24000-000000-9860 - Revit Architecture - PC User Manual

Name
Maximum ridge height
Dimensions
Slope
Thickness
Area
Volume
Identity Data
Comments
Mark
Phasing
Phase Created
Phase Demolished

Roof Boundary Line Properties

Name
Constraints
Defines roof slope
Overhang
638 | Chapter 11 Working with Architectural Components
Description
the effects of this property more clearly, set a value for Plate Offset from Base other
than 0. (See Roof Boundary Line Properties
This property only affects roofs created by picking walls.
The maximum height of the top of the roof above the base level of the building.
You can set a maximum allowable ridge height using the Max Ridge Height com-
mand. This is a read-only value. This property is enabled only when creating a roof
by footprint.
Changes the value of the slope-defining line to the specified value, without the need
to edit the sketch. The parameter initially displays a value if there is a slope-defining
line. If there is no slope-defining line, the parameter is blank and disabled.
Indicates the thickness of the roof. This is a read-only value.
The area of the roof. This is a read-only value.
The volume of the roof. This is a read-only value.
Comments about a particular roof.
A label applied to a roof. Usually a numeric value. This value must be unique for
each roof in a project. Revit Architecture issues a warning if the number is already
used but allows you to continue using it. You can see the warning using the Review
Warnings command. See Reviewing Warning Messages
The phase when the roof was created.
The phase when the roof was demolished.
Description
For footprint roofs, sets a roof line to be a slope-defining line.
Adjusts the horizontal offset of the line from its associated wall. Available only when
picking walls.
on page 638.)
on page 1334.
