Text Note Properties

Parameter names, values, and descriptions for text notes. Many values are modifiable.

Modifying Text Note Properties

1 In a project view, select a text note and click
2 In the Element Properties dialog, edit text note instance properties.
3 Click Edit/New to edit text note type properties.
4 Click OK.
See Specifying Text Note Styles

Text Note Type Properties

Name
Graphics
Color
Line Weight
Background
Leader Arrowhead
Text
Text Font
Text Size
Tab Size
Bold
NOTE Changes made to type properties affect all text notes of that type in the project. You can click
Duplicate to create a new text note type.
on page 491.
Description
Sets the color of the text and the leader line.
Sets the thickness of the line that surrounds the text when you select the text and
the thickness of the leader line. You can change the definition of the line weight
numbers using the Line Weights command in the Settings menu. See
on page 486.
Sets the background for the text note. With Opaque, the background of the note
itself covers material behind it. Transparent allows you to see material behind the
note. This is useful with text notes placed in color-defined rooms.
Sets the arrowhead style for the leader as defined by the Arrowheads command.
See
Sets the Microsoft
Sets the size of the typeface.
Sets tab spacing in a text note. When you create a text note, you can press TAB
anywhere in the text note, and a tab appears at the specified size.
Sets the text typeface to bold.
Specifying Arrowhead Styles
®
True Type fonts for the text note. The default font is Arial.
.
on page 491.
Text Note Properties | 1031
Line Weights
