Visibility of Imported Geometry

The Visibility command is also available for imported geometry; it functions very similarly to the line
visibility command. After importing the geometry, select it and click Visibility on the Options Bar. Specify
the views and detail levels in which the imported geometry should appear, for example, plan and 3D views
and coarse and medium detail levels. When you load the family into a project and place an instance of it,
the imported geometry displays based on the settings you specified.

Visibility During Sketching

You can set geometry visibility during sketch mode. Sketch the geometry, select it, and click Visibility from
the sketching toolbar.

Setting Detail Level

1 On the Family Editor Design Bar, click Modify and select the family geometry.
2 On the Options Bar, click Visibility.
3 In the Family Element Visibility Settings dialog, select the detail level at which you want the

Instance Parameters and Shape Handles

As you create families, you can set labeled dimensions as instance parameters; the parameters are modifiable
when the family instance is placed in the project. Labeled dimensions set as instance parameters can also
have shape handles that appear when the family is loaded into a project.

Creating Instance Parameters

1 Sketch family geometry using Family Editor tools.
2 Create dimensions for the family geometry.
3 Label the dimensions. See
4 Select the dimensions and, on the Options Bar, click Instance Parameter.
5 On the Design Bar, click Family Types.
6 Save changes and load the family into a project and click
geometry to display in a project: Coarse, Medium, or Fine and click OK.
NOTE If you label dimensions by selecting a label on the Options Bar, you can check the Instance
Parameter option without re-selecting the dimensions.
In the Family Types dialog, notice the new instance parameter. The (default) label indicates the
value for the instance parameter when you place the family in the project. For example, if you
create an instance parameter called length with a default value of 3000 mm, the family instance
will have a length of 3000 mm when placed in the project.
a family, see Loading Families
Notice that the labeled dimensions appear as parameters in the Instance pane of the Element
Properties dialog. You can change the values in the dialog. See
page 75.
Labeling Dimensions on page 359.
on page 352.
. For information about loading
Element Properties Dialog
Visibility of Imported Geometry | 363
