To tag mass floors
1 Open a view in which you can apply tags.
2 Apply tags to mass floors.
3 (Optional) If the tag displays the Usage label, click the Usage text and enter a value.

Assigning a Usage to a Mass Floor

After creating mass
on the design. See
Assign a usage to a mass floor using any of the following methods:
Schedule: Include the Usage field in a mass floor schedule. Then assign usages within the schedule. Open
the schedule, click the Usage column for a row, and enter text. If you have already entered usage values
for other mass floors, you can click in the field and select a value from a list. See
Schedule
Tag: To tag mass floors in a view, use a mass floor tag that displays the usage assigned to each mass floor.
Click the tag to change a usage value. See
Properties: Access the Element Properties dialog of a mass floor to assign a value to the Usage parameter,
as follows.
To assign a usage to a mass floor
1 In a view, right-click a mass floor, and click Element Properties.
2 In the Element Properties dialog, for Usage, enter a value.
3 Click OK.

Examples of Conceptual Design Analysis

The following topics provide examples of the different types of analysis that you can perform on conceptual
designs.
The analysis examples use the following massing study.
You can tag elements in 2D views, including plans, sections, and elevations. You cannot tag
elements in 3D views.
See Applying a Tag on page 1066 and
NOTE If you have trouble tagging a mass floor, move the cursor over the floor and press TAB. (Pressing
TAB changes the focus from the mass to the mass floor.) Then click the mass floor to tag it.
When you enter usage values in tags, other areas of the project (such as element properties and
mass floor schedules) update with the information.
floors, you can assign usages to them. Then you can perform various types of analysis
Examples of Conceptual Design Analysis
on page 527.
Tag All Not Tagged on page 1067.
on page 529.
Tagging Mass Floors on page 528.
Assigning a Usage to a Mass Floor | 529
