Hiding a Revision Cloud

You can hide revision clouds in a view. The method you use to hide revision clouds can determine whether
the revision information (for the hidden clouds) displays in the revision schedule of a sheet.
To hide revision clouds but include their revisions in a revision schedule, use either of the following methods:
Sheet Issues/Revisions dialog. (See
indicate whether revision clouds and tags display for each revision. This setting affects all views in the
project.
Hide in view > Category. In a view, select one or more revision clouds, right-click, and click Hide in
view Category. This command hides all clouds in the view.
To hide revision clouds and omit their revisions from a revision schedule, use either of the following methods.
By default the revision schedule of the view s sheet does not include the revision information for these
clouds. However, you can force the sheet to list the revisions, if desired. See
Include in a Revision Schedule
Crop region. If all or part of a revision cloud is outside the model crop region of a view, the cloud does
not display in the view. See
Hide in view > Elements. In a view, select one or more revision clouds, right-click, and click Hide in
view Elements.

Revision Cloud Properties

The following table describes parameters for revision clouds. To see or change these parameters, right-click
a revision cloud in a view, and click Element Properties.
Name
Revision
Revision Number
Revision Date
Issued to
Issued by
Mark
Comments
Entering Revision Information
on page 1018.
Crop Regions on page 163.
Description
The revision assigned to the cloud. To change the assigned revision, select a revision from the
list. (See Entering Revision Information
on page 1015.)
A number assigned to the cloud, which displays in a revision tag and a revision schedule on a
sheet. Its value depends on the assigned revision and the cloud numbering method. (See
Cloud Numbering by Project or by Sheet
The date of the assigned revision, based on the Date column of the Sheet Issues/Revisions dialog.
This value is read only.
For the assigned revision, the value of the Issued to column of the Sheet Issues/Revisions dialog.
This value is read only.
For the assigned revision, the value of the Issued by column of the Sheet Issues/Revisions dialog.
This value is read only.
A unique identifier for the revision cloud.
A text field that you can use to store information about the revision cloud.
on page 1009.) Use the Show column to
Specifying the Revisions to
on page 1009 and Assigning a Revision to a Revision Cloud
on page 1011.) This value is read only.
Revision
Revision Clouds | 1017
