Name
Keynote
Model
Manufacturer
Type comments
URL
Description
Assembly description
Assembly code
Type Mark
Cost

Architectural Column Instance Properties

Name
Constraints
Base Level
Base Offset
Top Level
Top Offset
Moves with Grids
Room-bounding
Identity Data
Description
Add or edit the column keynote. Click in the value box to open the Keynotes dialog.
See Keynotes on page 1058.
The model type of the column.
The manufacturer for the column materials
Specific building or design comments about the column.
Sets a link to a web page. For example, a manufacturer's web page.
Provides a description of the column.
Description of the assembly based on the assembly code selection.
Uniformat assembly code selected from hierarchical list.
A value to designate the particular column. This value must be unique for each
column in a project. Revit Architecture warns you if the number is already used but
allows you to continue using it. (You can see the warning using the Review Warnings
command. See Reviewing Warning Messages
Cost of the materials for constructing the column. This information can be included
in a schedule.
Description
Specifies the level on which the base of the column rests. The default is Level 1.
Specifies distance from the base level. The default is 0.
Specifies the level that the top of the column reaches. The default is 1.
Specifies distance from the top level. The default is 0.
Columns move when grid lines are moved.
Determines whether the column is room-bounding.
on page 1334.)
Architectural Column Properties | 699
