7 Save the family by clicking File menu

Specifying How a Column Displays in Plan View

For a column family, you can select the option Show family pre-cut in plan views, in the Family Category
and Parameters dialog. When you select this option and load the family into a project, the column displays
in a plan view using the cut plane specified in the plan view of the family.
1 Open a column family or start a new column family.
2 Click Settings menu
3 In the Family Category and Parameters dialog, under Family Parameters, select or clear the
4 Click OK.
5 Save the column family.
extension.
Family Category and Parameters.
parameter, Show family pre-cut in plan views.
When loaded into a project, if you want the
column to display in plan view
based on the cut plane of the project's plan view,
consistently, regardless of the cut plane of the
project's plan view,
After you load the column family into a project, the column displays based on the parameter
settings you specified within the Family Editor.
In the 2 examples shown below, the same column is loaded into a project. A horizontal line has
been added to the elevation representation so you can see the location of the plan view s cut
plane. In the first image, the parameter, Show family pre-cut in plan views, is not selected; the
column displays in plan using the cut plane of the project s plan view. In the second image, the
same column family has the parameter, Show family pre-cut in plan views, selected. Notice the
change in the column s plan view display even though the project s plan view is using the same
cut plane as the previous image.
Save. Revit Architecture saves the file with an RFA
then
clear the parameter, Show family pre-cut in plan views.
select the parameter, Show family pre-cut in plan views.
The column displays using the cut plane specified within
the Family Editor plan view.
Specifying How a Column Displays in Plan View | 427
