Ceiling Sketch Line Properties - Autodesk 24000-000000-9860 - Revit Architecture - PC User Manual

Name
Perimeter
Area
Volume
Identity Data
Comments
Mark
Phasing
Phase Created
Phase Demolished

Ceiling Sketch Line Properties

Name
Constraints
Level
Defines Slope
Defines Constant Height
Offset from Base
Dimensions
Slope
Description
The ceiling's perimeter. This is a read-only parameter.
The ceiling's area. This is a read-only parameter.
The ceiling's volume. This is a read-only parameter.
Specific comments on the ceiling.
A user-defined label for the ceiling. This value must be unique for each ceiling in a
project. Revit Architecture warns you if the number is already used but allows you
to continue using it. (You can see the warning using the Review Warnings command.
See Reviewing Warning Messages
The phase when the ceiling was created.
The phase when the ceiling was demolished.
Description
The level at which the ceiling resides.
Sets a ceiling line to slope-defining. This property is enabled when Defines Constant
Height is turned on.
Enables a ceiling line to have a constant height above the level on which it is
sketched. This property is for defining slope. For example, to define slope you can
set 2 parallel lines to be at a constant height and then set an offset for each line, or
you can set a single line to be at a constant height, slope-defining, and then set its
slope. See Sloped Ceilings on page 653.
Sets the height of the ceiling line above the level on which it is sketched. This
property is enabled when Defines Constant Height is turned on.
Sets the slope angle for the selected ceiling line. This property is enabled when
Defines Slope is turned on.
on page 1334.)
Ceiling Properties | 657
