Spot Elevations
This tool allows the placement of Spot Elevations when the type parameter Rotate with Component is
selected. This is similar to tags in that they are filtered by this parameter.
Beam Elevation (Project) calculates elevation from the lowest level of the project.
Create/modify types gives you the option of creating a custom spot elevation. When selected, the Family
Type Properties dialog opens to edit the spot elevation tag (see Creating Family Types in a Project on page
349).
Beam Elevation (Relative), enables the Relative Base pull down menu. This menu allows selection of the
base relative level for elevation calculation.
NOTE Only one spot elevation type can be placed at a time. If you change the spot elevation type in any of the
12 locations (6 for the level and 6 for sloped), it will change all 12 spot elevation type settings in the beam
annotations tool.
The Display Elevation pull down menu selects the location of elevation measurement on the beam.
