Resizing or Flipping Roof Fascias

To resize roof fascia
1 In the drawing area, select the fascia.
2 Move the drag controls to the desired location.
To flip roof fascia
1 In the drawing area, select the fascia.
2 If you are in a 3D view, click the flip controls that appear to flip the fascia around the vertical

Adding or Removing Segments of the Fascia

1 In the drawing area, select the fascia.
2 On the Options Bar, click Add or Remove Segments.
3 Click a reference edge to add a fascia or remove a fascia.

Changing Mitering Options for Roof Fascia

1 In the drawing area, select the fascia.
624 | Chapter 11 Working with Architectural Components
NOTE Fascia profiles miter correctly only around a square cut roof. The roof in this image was created
by running a fascia along the edge of a roof with a Two-Cut Square rafter cut. For information on
setting this property, see Creating a Plumb Cut, Two-Cut Plumb, or Two-Cut Square Eave
618.
If there are many elements near the fascia that make selection difficult, you can use the filter
selection tool to select the fascia. Highlight the area where the fascia is using a pick box, and
on the Options Bar, click
For more information on using drag controls, see
or horizontal axis.
If you are in a 2D view, right-click the fascia and select Flip About Horizontal Axis or Flip About
Vertical Axis.
If many elements near the fascia make selection difficult, use the filter selection tool to select
the fascia. Highlight the area near the fascia is using a pick box, and click
Bar. Select Roof (Fascias), and click OK.
NOTE Watch the status bar. It will indicate valid references, or points where you can add or remove
fascia. For example, if you are adding fascia to a roof, a valid reference might be: Roofs : Basic Roof
: Reference. When you add or remove segments of fascia in a section view, place the cursor near the
corners of the element to highlight the reference or press TAB.
If many elements near the fascia make selection difficult, use the filter selection tool to select
the fascia. Highlight the area near the fascia is using a pick box, and click
Bar. Select Roof (Fascias) and click OK.
. Select Roof (Fascias) and click OK.
Controls and Shape Handles
on page
on page 279.
on the Options
on the Options
