Name
Single/Upper Value
Single/Upper Value Prefix
Single/Upper Value Suffix
Lower Value
Lower Value Prefix
Lower Value Suffix

Spot Coordinate Type Properties

You can specify various parameters to change the appearance of the spot coordinate.
Name
Constraints
Rotate with Component
Graphics
Symbol
Leader Arrowhead
Leader Line Weight
Leader Arrowhead Line Weight
Color
Text
Width Factor
244 | Chapter 5 Using Dimensions and Constraints
Description
Top & Bottom Elevation displays the top and bottom elevations of the element.
This parameter is enabled when you place a spot elevation in a plan view.
The actual elevation of the selected point or the upper elevation value. This is a read-
only value.
Add prefix text to the single or upper dimension value.
Add suffix text to the single or upper dimension value.
The actual lower elevation value reported. This is a read-only value.
Add prefix text to the lower dimension value.
Add suffix text to the lower dimension value.
Description
When selected, the spot coordinate rotates with the component.
Changes the look of the symbol head with the spot coordinate.
Sets the appearance of the leader arrowhead. The value None removes the arrow-
head. To define an arrowhead, see
Sets the weight of the leader line. The higher the value, the thicker the line.
Sets the arrowhead line weight. The higher the value, the thicker the arrowhead
line.
Sets the color of the spot coordinate. Click the button to open the color picker.
Specify a ratio to define the elongation of the text string. A value of 1.0 has no
elongation.
Specifying Arrowhead Styles on page 491.
