2 Move the cursor over the part of the next element to resize and press TAB until the desired handle
3 Repeat Step 2 for the remaining elements, until handles on all desired elements are selected.
4 Click the handle of one of the selected elements, and drag it to resize.
The other selected elements are resized at the same time.

Resizing Graphically

Graphical resizing requires 3 clicks: the first click determines the origin, and the next 2 clicks define the
scale vectors. Revit Architecture calculates a scale factor by determining the ratio of the lengths of the 2
vectors. For example, suppose you sketch a first vector that is 5 feet and a second vector that is 10 feet. This
creates a scale factor of 2. As a result, the elements become twice their original size.
To resize elements graphically:
1 Select elements to resize.
2 Click Edit menu
3 On the Options Bar, select Graphical.
4 In the drawing area, click to set the origin.
5 Move the cursor to define the first vector.
6 Click to set that length.
7 Move the cursor again to define the second vector.
8 Click to set that point.
The selected element resizes so that the ends of vector 1 now coincide with those of vector 2.
is highlighted. While pressing CTRL, click to select it.
Remember to press CTRL when you click to select another element.
NOTE To deselect a selected element (without deselecting other elements), move the cursor over
the selected element and, while pressing SHIFT, click the element.
Be sure to select only supported elements, such as walls and lines. The Resize tool is unavailable
if your entire selection contains just one non-supported element.
Resize, or click
The origin is the point from which the size of the element will change. The cursor snaps to
various references. Press TAB to change the snap points.
TIP You can use listening dimensions to enter values for the lengths of the vectors.
on the Edit toolbar.
