2 Select the building pad.
3 On the Options Bar, click Edit.
4 On the Design Bar, click Slope Arrow.
5 Sketch the slope arrow on the building pad.
6 With the slope arrow highlighted, click
7 For Specify, choose either Height at Tail or Slope.
8 Click OK.
9 Click Finish Sketch.

Building Pad Properties

You can change the properties of building pad types and building pad instances.

Modifying Building Pad Properties

1 Open a site or plan view.
2 Select the building pad.
3 Click
4 Property changes made to a building pad type affect all building pads of this type in the project.
5 When finished, click OK.

Building Pad Type Properties

Name
Construction
NOTE Use the TAB key to cycle through the selection options. Selection options are displayed on
the left side of the status bar.
If you select Height at Tail, then select a level and specify a height offset for both the tail
and head of the arrow
If you select Slope, then select a level and specify a height offset for the tail, then the input
value for Slope
NOTE Use the TAB key to cycle through the selection options. Selection options are displayed on
the left side of the status bar.
(Element Properties).
To change properties of the building pad instance, change the values in the Element Properties
dialog.
To change the properties of the building pad type, click Edit/New in the Element Properties
dialog, and change the properties as desired.
(To create a new building pad type, click Duplicate.)
Description
(Element Properties).
Building Pad Properties | 905
