2 Click Modelling menu
3 Click Set Work Plane on the Design Bar to select a different work plane. See
4 On the Design Bar, click Run, and then click in the drawing area where you want to start the
5 Move the cursor to set the angle for the stair footprint.
6 To create a straight run of stairs, click outside the rectangle on the end away from the start point.
7 To create a jogged set of stairs, click for the end of the first run, move the cursor, and click the
8 Edit the footprint, if desired.
9 To change the properties of the stairs, click
10 On the Design Bar, click Finish Sketch.

Creating Spiral Staircases

1 Open a plan or 3D view.
2 Click Modelling menu
3 Click Set Work Plane on the Design Bar to select a different work plane. See
4 On the Options bar, click
5 In the drawing area, click to select a center point for the spiral.
6 Click a start point.
7 Click an end point to complete the spiral.
Planes on page 265.
stairs.
start and end points for the second run.
Continue this process if there is more than one jog.
For a description of stair properties and their values, see
Revit Architecture generates a staircase with automatic railings.
Completed stairs in 3D with default railings and balusters
Planes on page 265.
Stairs, or on the Modelling tab of the Design Bar, click Stairs.
Stairs, or on the Modelling tab of the Design Bar, click Stairs.
.
Sketching and Work
, and click Edit/New.
Stair Properties on page 671.
Sketching and Work
Creating Spiral Staircases | 665
