Rotate Controls

Use rotate controls to drag an element or text note to a desired degree of rotation around a central axis.
For more information, see
Rotate control

Dimension Text Controls

Dimension text controls are blue squares that display on selected dimension elements that you have added
to a drawing. Drag a control to move dimension text away from the dimension line.
NOTE You may need to zoom in to see dimension text controls.
For more information, see
Dimension text control shown in blue

View Controls

Double-click a view control to open a new view associated with an element. For example, when you
double-click a view control for level lines, Revit Architecture opens the appropriate floor plan level. When
you double-click a view control with a section level, Revit Architecture opens the appropriate section view.

Spacebar

Use the SPACEBAR to flip a selected element. You can select multiple elements and flip them all at the same
time. Free standing families, such as furniture and columns, rotate 90 degrees each time you press the
SPACEBAR. You cannot flip annotations.
Rotating Elements on page 308.
Dimension Witness Lines on page 233.
