2 On the Options Bar, click:
3 To move a control point, drag it to a new location.
4 To move spline end points, select the spline.

Model Line Properties

You can modify properties for straight lines, arc lines, circles, tangent lines, and fillet lines.
Modifying Line Properties
1 From a plan view, select the line and click
2 In the Element Properties dialog, edit line instance parameters.
3 When you are finished, click OK.
Straight Line Properties
Name
Constraints
Work Plane
Moves With Nearby Elements
Graphics
Line Style
Detail Line
Dimensions
Length
744 | Chapter 11 Working with Architectural Components
Add Control to add a control point to the spline. Place the cursor over a spline chord and
watch the status bar. When it says Reference, click to place a control.
A control point is added to the center of the chord.
Delete Control to delete a spline control point. Select a control point for deletion.
The spline adjusts after control point deletion.
To move the entire spline, drag the end controls, which display as blue dots.
To modify the spline curve between the end point and the next control point, select the end
control, press TAB, then drag the end control point.
Description
The work plane to which the line is related.
Determines whether the line moves with nearby elements.
Sets the line style type as defined in the Object Styles dialog. See
page 484.
The actual length of the line.
.
Object Styles on
