Use a curtain system type with a curtain grid layout. For more information on specifying a
curtain grid layout by type, see
3 To select more than one face, select Multiple. Otherwise, clear this option.
4 Place the cursor on a mass face.
Cursor highlighting mass face
TIP Drag a pick box over the entire shape to make a curtain system on the entire form.
5 Click to select the face.
A curtain system is placed on the face immediately if the Multiple option is cleared.
6 If you selected Multiple, do the following:
Continue selecting faces.
You can add or remove faces from the selection by clicking them. The cursor indicates
whether you are adding (+) or removing (–) a face. To clear the selection of all faces and start
selecting again, on the Options Bar, click Clear.
When finished selecting faces, on the Options Bar, click Create System.
Revit Architecture creates a curtain system on each of the selected faces.
7 On the Design Bar, click Modify.
Curtain systems created with the Curtain System by Face command do not automatically update if you
change the mass face. To update the curtain system, use the Remake command. See
Host Shapes on page 554.
Type-Driven Curtain Element Layout
Creating Curtain Systems from Mass Instances | 549
on page 705.
Remaking Face-Based
