Resizing or Flipping Roof Gutters

To resize roof gutters
1 In the drawing area, select the gutter.
If many elements near the gutter make selection difficult, use the filter selection tool to select
the gutter. Highlight the area near the gutters using a pick box, and click
Bar. Select Roof (Gutters), and click OK.
2 Move the drag controls to the desired location.
For more information on using drag controls, see
To flip roof gutters
1 In the drawing area, select the gutter.
2 If you are in a 3D view, click the flip controls to flip the gutter around the vertical or horizontal
axis.
If you are in a 2D view, right-click the gutter and select Flip About Horizontal Axis or Flip About
Vertical Axis.

Adding or Removing Segments of the Gutter

1 In the drawing area, select the gutter.
If many elements near the gutter make selection difficult, use the filter selection tool to select
the gutter. Highlight the area near the gutter is using a pick box, and click
Bar. Select Roof (Gutters), and click OK.
2 On the Options Bar, click Add or Remove Segments.
3 Click a reference edge to add a gutter or remove a gutter.
NOTE Watch the status bar. It will indicate valid references, or points where you can add or remove
gutters. For example, if you are adding gutters to a roof, a valid reference might be: Roofs : Basic
Roof : Reference. When you add or remove segments of a gutter in a section view, place the cursor
near the corners of the element to highlight the reference, or press TAB.

Changing Horizontal and Vertical Offset

You can change the horizontal or vertical offset of a gutter through its properties or by graphically moving
the gutter. See Slab Edge Properties
Horizontal Move
To move a single gutter segment, select the gutter and drag it horizontally.
To move a multi-segmented gutter, you need to select the shape handle of the gutter. Place the cursor over
the gutter and press TAB to highlight the shape handle. Watch the status bar to be sure you are highlighting
the shape handle. Click to select the shape handle. Move the cursor left or right to change the horizontal
offset. This affects the horizontal offset of all segments of the gutter, so that the segments are symmetrical.
on page 646.
Controls and Shape Handles
Roof Gutters | 631
