Name
Top is Attached
Top Extension Distance
Room Bounding
Related to Mass
Structural
Rebar Cover - Exterior Face
Rebar Cover - Interior Face
Rebar Cover - Other Face
Estimated Reinforcement Volume
Structural Usage
Dimensions
Length
Area
Volume
Identity Data
Comments
Mark
Phasing
Phase Created
848 | Chapter 12 Working with Structural Components
Description
Indicates whether the top of the wall is attached to another component, such
as a slab. This is a read-only value.
Indicates the distance you have moved the top of the layers in a wall. See
Compound Structure on page 748. This parameter is enabled when the layers of
a wall are set to extendable.
Indicates whether the wall is part of a room boundary. This parameter is enabled
after you place the wall.
This is a read-only value.
Specifies the rebar cover distance from the wall exterior face.
Specifies the rebar cover distance from the wall interior face.
Specifies the rebar cover distance from the face of adjacent element.
Specifies the estimated reinforcement volume of the selected element. This is a
read-only parameter that only displays when rebar has been placed.
The structural use of the wall.
Indicates the length of the wall. This is a read-only value.
Indicates the area of the wall. This is a read-only value.
Indicates the volume of the wall. This is a read-only value.
A field for entering comments about the wall.
A label created for the wall. This value must be unique for each element in a
project. Revit Architecture warns you when the number is already used but allows
you to continue using it. You can see the warning using the Review Warnings
command. See Reviewing Warning Messages
Indicates in which phase the wall component was created. See
on page 1263.
on page 1334.
Project Phasing
