Wall Foundation Type Properties - Bearing - Autodesk 24000-000000-9860 - Revit Architecture - PC User Manual

Name
Manufacturer
Type Comments
URL
Description
Assembly description
Assembly Code
Type Mark
Cost

Wall Foundation Type Properties - Bearing

Name
Materials and Finishes
Material
Structural
Structural Usage
Dimensions
Width
Foundation Thickness
Default End Extension Length
Do Not Break At Inserts
856 | Chapter 12 Working with Structural Components
Description
The foundation manufacturer.
A field for placing general comments about the foundation type. This information
can be included in a schedule.
A link to a web page that may contain type-specific information.
Enter an optional description of the wall foundation.
Describes the assembly, based on the assembly code selection. This is a read-only
parameter.
The uniformat assembly code selected from a hierarchical list.
A value that designates the particular foundation. This value must be unique for
each element in a project. Revit Architecture warns you when the number value is
already used, but allows you to continue using it. You can see the warning using
the Review Warnings command. See
The pricing of the foundation.
Description
Specifies the concrete to be used.
Specifies the wall usage type: either Retaining or Bearing. For information on Retain-
ing type, see Wall Foundation Type Properties - Retaining
Specifies the overall width of the bearing wall foundation.
Specifies the foundation thickness.
Specifies the distance the foundation will extend beyond the end of the wall.
Selecting this parameter forces the foundation to be continuous and not break when
openings are applied to its host wall.
Reviewing Warning Messages
on page 855.
on page 1334.
