A wall with a split face (around the window) before painting
A wall with a split face (around the window) after painting
To split a face:
1 Click Tools menu
2 Place the cursor on the element face to highlight it. You may need to press TAB to select the
desired face.
3 Click to select the face.
4 Sketch the face area to split. For more information about the sketching tools, see
page 251.
NOTE The sketch must be in a closed loop inside the face or an open loop that ends on the boundary
of the face.
Split Face, or click on the Tools toolbar.
Sketching on
Splitting Faces | 337
