2 In the Project Parameters dialog, click Add.
3 In the Parameter Properties dialog, under Parameter Type, select Shared parameter, and click
4 In the Shared Parameters dialog, select the appropriate parameter from the appropriate parameter
5 In the Parameter Properties dialog, under Categories, select the categories to which you want
6 Under Parameter Data, select Instance or Type to store the parameter by element instance or
7 For Group parameter under, select the heading under which the parameter should display in
8 Click OK.

Fill Patterns

Fill patterns control the appearance of surfaces that are cut or shown in projection. Use the Fill Patterns
command to create or modify drafting and model patterns.
Model Patterns
Model patterns represent actual element appearance on a building, such as brick coursing or ceramic tile on
a wall, and are fixed with respect to the model. This means they scale with the model, so as the view scale
changes, the pattern scales accordingly.
Lines in model patterns represent actual lines on a building object, such as brick, tile, and parquet lines and
are in measurable units on the model. Like other elements in Revit Architecture, model pattern lines can be
edited. You can:
Move pattern lines by dragging or by using the Move command.
Create dimensions that reference pattern lines; resize dimensions to move pattern lines.
Rotate the pattern.
Align pattern lines to other elements, such as reference planes, lines, windows.
You can apply model patterns to families and modify them in the Family Editor only. After you have placed
an instance of the family in a project view, you cannot modify the pattern.
Select.
group, and click OK.
If you click Edit, the Edit Shared Parameters dialog displays. From this dialog, you can open a
different shared parameter file or add new parameters. See
Groups, and Parameters
to apply this parameter.
If the shared parameter provides project-specific information, select the Project Information
category. You can then click Settings menu
parameter s value.
If the shared parameter provides sheet-specific information, select the Drawing Sheet category.
The parameter is then listed in each sheet s view properties.
TIP If you add a shared parameter to the Drawing Sheets or Project Information category, you can
add the parameter to a titleblock family, so you can have custom parameters on the titleblock. See
Adding Custom Fields to a Title Block
family type.
For more information on instance and type properties, see
on page 76.
the Element Properties dialog.
on page 442.
Project Information to see or change the
on page 992.
Creating Shared Parameters Files,
Instance Properties and Type Properties
Fill Patterns | 449
