Modifying Floor Properties

1 If you are in sketch mode, click Floor Properties on the Design Bar. If you are in a plan view,
select the floor, and click
2 In the Element Properties dialog, edit floor instance parameters.
3 Click Edit/New to edit floor type parameters.
NOTE Changes made to type parameters affect all floors of this type in the project. You can click
Duplicate to create a new floor type.
4 Click OK.

Modifying Floor Sketch Line or Slope Arrow Properties

1 If you are in a plan view, to enter sketch mode, select the floor and, on the Options Bar, click
Edit.
2 In sketch mode, select the floor sketch line or slope arrow, and click
3 In the Element Properties dialog, edit the sketch line or slope arrow properties.
4 Click OK.

Floor Type Properties

Name
Construction
Structure
Default Thickness
Graphics
Coarse Scale Fill Pattern
Coarse Scale Fill Color
Identity Data
Keynote
Model
.
Description
Creates the composition of a compound floor. See
748.
Indicates the thickness of the floor type, which is determined by the cumulative
thickness of its layers. This is a read-only property.
The fill pattern for a floor displayed at a coarse detail level.
Applies a color to the fill pattern for a floor in a coarse-scale view.
Add or edit the floor keynote. Click in the value box to open the Keynotes dialog.
See Keynotes on page 1058.
The model type for the floor.
.
Compound Structure on page
Floor Properties | 647
