Name
Rebar Cover - Top Face
Rebar Cover - Bottom Face
Rebar Cover - Other faces.
Estimated Reinforcement Volume
Dimensions
Volume
Identity Data
Comments
Mark
Phasing
Phase Created
Phase Demolished
Structural Analysis
Top Release
Top Fx
Top Fy
Top Fz
Top Mx
Description
Applies to concrete columns only. Sets the rebar cover distance from the column
top face.
Applies to concrete columns only. Sets the rebar cover distance from the column
bottom face.
Applies to concrete columns only. Sets the rebar cover distance from the column
to other element faces.
Specifies the estimated reinforcement volume of the selected element. This is a
read-only parameter that only displays when rebar has been placed.
Volume of the selected column, is a read-only value.
User comments.
A label created for the column. Possible use: shop mark. This value must be unique
for each element in a project. Revit Architecture warns you if the number is already
used but allows you to continue using it. You can see the warning using the Review
Warnings command. For more information, see
page 1334.
Indicates in which phase the column component was created. For more information,
see Project Phasing on page 1263.
Indicates in which phase the column component was demolished. For more inform-
ation, see Project Phasing on page 1263.
Either fixed, Pinned, Bending Moment or User-Defined. User-Defined allows you
to enable/disable each of the top release conditions.
Translational release at the top end of the column along the x-axis.
Translational release at the top end of the column along the y-axis.
Translational release at the top end of the column along the z-axis.
Rotational release at the top end of the column along the x-axis.
Reviewing Warning Messages
Structural Column Properties | 765
