6 On the Design Bar, click Slope Arrow again, and sketch a second slope arrow that begins from
7 Click Finish Sketch, and open a 3D view to see the results.
620 | Chapter 11 Working with Architectural Components
Correct placement of cursor for slope arrow
Incorrect placement of cursor for slope arrows
the other end point of the segment.
Properly sketched slope arrows
