Vertical Move
Select the slab edge, and drag it up or down. If the slab edge is multi-segmented, all segments move up or
down the same distance.
Slab edge moving vertically in section

Floor Slab Edge Properties

Parameter names, values, and descriptions for floor slab edges. Floor slab edges are classified under host
sweeps. Values are modifiable.
Floor Slab Edge Type Properties
Name
Profile
Material
Floor Slab Edge Instance Properties
Name
Length
Volume (floor slab edges only)
Vertical profile offset
Horizontal profile offset
Angle

Floor Properties

You can modify several properties for floors, including the slope and the level. You can also modify properties
for an individual floor sketch line and the floor slope arrow.
646 | Chapter 11 Working with Architectural Components
Description
The profile shape for the particular host sweep. Select from a list of predefined profiles,
or create your own profile using the profile-hosted.rft template. See
on page 371.
Specifies the appearance of the host sweep in various views, including a raytraced
model. See Materials on page 459.
Description
The actual length of the host sweep.
The actual volume of the floor slab edge.
Moves the host sweep above or below the edge on which you created it.
Moves the host sweep forward or backward from the edge on which you created
it.
Rotates the host sweep to the desired angle.
Profile Families
