Name
Volume
Identity Data
Comments
Mark
Phasing
Phase Created
Phase Demolished
Structural Analysis
Start Release
Start Fx
Start Fy
Start Fz
Start Mx
Start My
Start Mz
End Release
End Fx
End Fy
End Fz
838 | Chapter 12 Working with Structural Components
Description
The volume of the selected brace element. This is a read-only value.
User comments.
A label created for the brace. Possible use: shop mark. This value must be
unique for each brace in a project. Revit Architecture warns you if the number
is already used but allows you to continue using it. You can see the warning
using the Review Warnings command. See
page 1334.
Indicates in which phase the brace component was created. See
Phasing on page 1263.
Indicates in which phase the brace component was demolished. See
Phasing on page 1263.
Specifies the start release condition: either Fixed, Pinned, Bending Moment,
or User Defined. User Defined allows you to enable/disable each of the start
release conditions.
The translational release at the start end of the brace along the local x-axis.
The translational release at the start end of the brace along the local y-axis.
The translational release at the start end of the brace along the local z-axis.
The rotational release at the start end of the brace along the local x-axis.
The rotational release at the start end of the brace along the local y-axis.
The rotational release at the start end of the brace along the local z-axis.
Specifies the end release condition: either Fixed, Pinned, Bending Moment
or User Defined. User Defined allows you to enable/disable each of the end
release conditions.
The translational release at the end of the brace along the local x-axis.
The translational release at the end of the brace along the local y-axis.
The translational release at the end of the brace along the local z-axis.
Reviewing Warning Messages
Project
Project
on
