To load braces from the Options Bar:
1 On the Structural tab of the Design Bar, click Brace.
2 On the Options Bar, click Load.
3 In the Open dialog, navigate to either the imperial or metric library, and open the
4 Select a brace type folder: either Steel, Light Gauge Steel, Concrete, or Wood, and click Open.
To load braces from the Element Properties dialog:
1 On the Structural tab of the Design Bar, click Brace.
2 On the Options Bar, click
3 In the Element Properties dialog, click Load.
4 In the Open dialog, navigate to either the imperial or metric library, and open the
5 Select a brace type folder: either Steel, Light Gauge Steel, Concrete, or Wood, and click Open.

Adding Structural Braces

You can add braces in either a plan view or in a framing elevation view.
To add a brace in a framing elevation view:
1 Open a framing elevation view.
2 If necessary, load additional braces from the Structural/Framing folder under the Library folder
Family dialog box
Structural Framing folder.
TIP You can also select an existing beam or brace in the project. On the Options Bar, click
Structural Framing folder.
of the Revit Architecture program group. For more information, see
on page 828.
.
Loading Structural Braces
Adding Structural Braces | 829
.
