Location line does not move when it is the origin point

Wall Properties

Walls have properties based on whether they are interior or exterior walls. You can modify the properties
of one wall type and set them for all walls of that type. For example, if you set properties for a basic interior
wall type, then all interior walls assume those property values. You can also select an instance of a wall and
change its parameters only.
NOTE Be aware that the type names do not update upon changing parameters. For example, you could set the
width of a 200 mm exterior wall to 250 mm and its name will not change.

Wall Type Properties

Name
Construction
Structure
Wrapping at Inserts
Wrapping at Ends
Width
Wall Function
Description
Click Edit to create compound walls. See
Sets the layer wrapping of walls at inserts. See
Sets the layer wrapping of wall end caps. See
Sets the width of the wall.
Sets a wall to exterior, interior, retaining, foundation, or soffit. Before creating the
wall, you can click , and you see the default instance values for wall function.
See Adding Interior and Exterior Walls
page 564. The value should be set to Soffit when the wall is attached to a ceiling. In
this case, the attachment is made to the surface of the ceiling, regardless of the
shape of the ceiling.
Compound Structure on page 748.
Layer Wrapping on page 751.
Setting Layer Wrapping
on page 562 and Adding Retaining Walls
Wall Properties | 603
on page 752.
on
