Name
Underline
Italic
Bold
Text Size
Text Offset from Leader
Text Offset from Symbol
Text Font
Text Background
Text Orientation
Description
Underlines the spot coordinate value and text.
Applies italic formatting to the spot coordinate value and text.
Applies bold formatting to the spot coordinate value and text.
Sets the size of the elevation text.
Offsets the text from the leader line.
Offsets the text away from the symbol.
You can use positive or negative values to move the text in the direction you require.
Sets the font for the elevation text.
Sets the background for the text. With opaque, the background of the text itself
covers objects behind it. Transparent allows you to see objects behind the text.
Changes the position of the text to read horizontally
or vertically.
When Rotate with Component is enabled, text orientation is relative to the host
element.
Dimension Properties | 245
