Automatic Aligned Dimensions with Walls
With automatic aligned dimensions, you can place a dimension on a wall with one click, eliminating the
need to pick all references. You can dimension an entire wall, a wall with intersecting walls, or a wall with
openings.
1 Click Drafting menu
2 On the Options Bar, do the following:
3 In the Auto Dimension Options dialog, select:
4 Click OK to close the Auto Dimension Options dialog.
5 Place the cursor on a wall so that the wall highlights, and click. If desired, continue to highlight
6 Move the cursor away from the walls so that a dimension line displays.
7 Click to place the dimension.
Aligned Dimensions with Arc Wall Centers
You can place aligned dimensions from the center of arc walls to other walls or lines.
1 Click Drafting menu
2 On the Options Bar, click
3 Move the cursor over the arc wall until the center mark (+ symbol) displays. You may need to
4 Click to start the dimension.
216 | Chapter 5 Using Dimensions and Constraints
Dimension, or on the Drafting tab of the Design Bar, click Dimension.
a Click
(Create Aligned Dimensions).
b For Pick, select Entire Walls.
c Click Options.
Openings to dimension a wall and its openings. Select Centers or Widths to set the references
for the openings.
If you select Centers, the dimension string uses the opening s center as a reference. If you
choose Widths, the dimension string measures the width of the opening.
Intersecting Walls to dimension a wall and its intersecting walls. When you select a wall to
place a dimension, a multi-segmented dimension string displays automatically.
Intersecting Grids to dimension a wall and its intersecting grids. When you select a wall to
place a dimension, the multi-segmented dimension string displays automatically and
references the perpendicular grids that intersect the wall centerline.
NOTE If a grid line is coincident with another wall reference point (for example, the wall end
point), then a witness line is not created for the grid. This avoids the creation of zero-length
dimension segments.
other walls to add them to the dimension string.
Dimension, or on the Drafting tab of the Design Bar, click Dimension.
zoom in to see the + symbol.
NOTE By default the arc center mark is invisible. You can dimension to it without displaying it by
moving the cursor over the arc until the center mark highlights. Arc center marks are only visible in
a plan view.
(Create Aligned Dimensions).
