To change the way that revision schedules display information
1 Open the title block for editing.
2 In the Project Browser, under Views (all)
3 In the Element Properties dialog, for Appearance, click Edit.
4 On the Appearance tab of the Revision Properties dialog, for Build schedule, select one of the
5 Click the Sorting/Grouping tab of the Revision Properties dialog. Make sure that the revision
6 Click OK twice.
7 If needed, adjust the position of the revision schedule on the title block.
8 To save the title block, click File menu
9 Load the title block into a project.

Adding Custom Fields to a Title Block

In general, a title block contains placeholders for 2 types of information:
Project-specific information. This information applies to all sheets in the project. Examples: project name,
client information, project address.
Sheet-specific information. This information differs for each sheet within a project. Examples: sheet
name, sheet number, reviewer, sheet issue date.
When you add a sheet to a project, the project-specific information in the title block displays the appropriate
information. You can enter the sheet-specific information directly on the sheet.
Revit Architecture provides default title block families. These title blocks include some project-specific
information fields and some sheet-specific information fields. If you want to add more information (custom
fields) to a title block, use shared parameters.
NOTE Use shared parameters (not project parameters) so that they are available to the title block families and
the projects that use them.
To add custom fields to a title block
1 Create (or edit) a shared parameter file, and add shared parameters to the file.
992 | Chapter 15 Preparing Construction Documents
See Modifying a Title Block
Properties.
following values:
Top-down: Column headings display at the top of the revision schedule. Revision rows start
at the top of the schedule and go down.
Bottom-up: Column headings display at the bottom of the revision schedule. Revision rows
start at the bottom of the schedule and go up.
schedule is sorted as desired.
a In the drawing area, select the revision schedule of the title block.
The status bar displays Schedule Graphics : Schedule Graphics : Revision Schedule.
b Drag the revision schedule to the desired location.
click Save.
See Loading a Title Block into a Project
on page 985.
Schedules, right-click Revision Schedule, and click
Save, specify a location and file name (if needed), and
on page 987.
