Name
Type Mark
Cost
Keynote

Beam System Instance Properties

Name
Constraints
3D
Elevation
Work Plane
Pattern
Layout Rule
Fixed Spacing
Centerline Spacing
Justification
Beam Type
Identity Data
Tag new members in view
826 | Chapter 12 Working with Structural Components
Description
A value that designates the particular beam; possibly the shop
mark. This value must be unique for each element in a project.
Revit Architecture warns you if the number is already used
but allows you to continue using it. You can see the warning
using the Review Warnings command. See
Messages
The pricing of the beam.
The beam keynote. Add or edit the value. Click in the value
box to open the Keynotes dialog. See
Description
Creates a non-planar beam system in which the elevation of a beam is defined by
its sketch lines. See
Creating a 3D Beam System
The vertical offset of beam system beams from the beam system work plane.
This is a read-only value that is dependent on the work plane where the element
was placed.
Rules for beam spacing. See
Beam System Layout Rules and Patterns
The space between beams. This parameter is only accessible for certain values of
the Layout Rule parameter. See
817.
The distance between beam centerlines. This is a read-only parameter.
Specifies the starting location (beginning, end, or center) of the beam system in
relation to the selected boundary.
The structural framing type to be used for creating beams in a beam system.
Specifies the view in which to display the beam system tag.
on page 1334.
Keynotes
on page 819.
Beam System Layout Rules and Patterns
Reviewing Warning
on page 1058.
on page 817.
on page
