Wall Foundation Properties

There are two types of wall foundations for structural use: bearing and retaining. You can modify the
properties for both types, including heel length, toe length, foundation thickness, and width.

Modifying Wall Foundation Properties

1 Select the wall foundation, and click
2 In the Element Properties dialog, edit wall foundation instance parameters.
3 Click Edit/New to edit wall foundation type parameters.
4 When you finish, click OK.

Wall Foundation Type Properties - Retaining

Name
Materials and Finishes
Material
Structural
Structural Usage
Dimensions
Toe Length
Heel Length
Foundation Thickness
Default End Extension Length
Do Not Break At Inserts
Identity Data
Model
NOTE Changes made to type parameters affect all wall foundations of this type in the project. You
can click Duplicate to create a new wall foundation type.
Description
Specifies the concrete to be used.
Specifies the wall usage type: either Retaining or Bearing. For information about the
Bearing type, see
Specifies the length from the edge of a wall to outside face of foundation.
Specifies the length from edge of a wall to inside face of foundation.
Specifies the foundation thickness.
Specifies the distance the foundation will extend beyond the end of the wall.
Selecting this parameter forces the foundation to be continuous.
The manufacturer internal number.
.
Wall Foundation Type Properties - Bearing
Wall Foundation Properties | 855
on page 856.
