Name
Italic
Underline
Width Factor

Text Note Instance Properties

Name
Graphics
Arc Leaders
Horizontal Align
Keep Readable

Leader Arrowhead Properties

Parameter names, values, and descriptions for text note leader arrowheads. Many values are modifiable.
Settings are global for the project.
To access properties for leader arrowhead types, click Settings menu
Arrowhead Properties
Name
Arrow Style
Fill Tick
Arrow Width Angle
Tick Size
Heavy End Pen Weight
1032 | Chapter 16 Annotating and Detailing
Description
Sets the text typeface to italic.
Underlines the text.
1.0 is the default for regular text width. The font width is scaled proportionately to
the Width Factor. Height is not affected.
Description
Converts a text note's leader to an arc leader.
Sets the justification of the text.
Text in the note remains readable whenever you rotate it. It never displays upside-
down.
Description
Sets the arrowhead shape on the leader line.
Fills the arrowhead.
Sets the width of the arrowhead. The larger the angle value, the wider the arrowhead.
Sets the overall size of arrowhead.
If Arrow Style is set to Heavy End Tick Mark, this setting specifies the size of the mark
or dot on the opposite end of the text note.
Annotations Arrowheads.
