6 In the drawing area, click the position the tag: for example, in a generic model tag template,
7 Edit the label parameters. See

Editing Multi-parameter Labels

You assign single or multiple parameters to labels with the Edit Label dialog.
The Catalog Parameters window contains the label parameters related to the tag type. The Label Parameters
window contains the Catalog Parameters that display in the label. Typically, this is a single parameter, but
you can detail more complex, concatenated labels.

Building a Label

You add and remove parameters by moving them between the windows:
Highlight a parameter in the Catalog Parameter window and click
the Label Parameter window.
Highlight a parameter in the Label Parameter window and click
into the Catalog Parameter window.
Labels display their parameters from the first to the last (top to bottom) as listed in the Label Parameter
window. You reorder the label by highlighting a parameter and shift its position using
Up) and

Shared Label Parameters

You can configure the label with shared external parameters of other families. You configure shared parameters
before moving them over to the Label Parameters window. The Category Parameters controls aid in this
integration:
place the cursor at the intersection of the two reference planes. The Edit Label dialog opens.
(Move Parameter Down).
Editing Multi-parameter Labels on page 429.
(Add Parameter) to move it into
(Remove Parameter) to move it
(Move Parameter
Editing Multi-parameter Labels | 429
