3 To change the appearance of the cloud, do the following:
To change the appearance of all revision clouds
1 In the project, click Settings menu
2 Click the Annotation Objects tab.
3 For Revision Clouds, change the values for Line Weight, Line Color, and Line Style.
4 Click OK.

Tagging a Revision Cloud

A revision tag identifies the revision assigned to each cloud in a view. (You enter revision information on
the Sheet Issues/Revisions dialog. See
To tag revision clouds
1 If the revision tag family is not yet loaded into the project, load it.
2 Open the view that contains revision clouds.
3 On the Drafting tab of the Design Bar, click Tag
4 In the drawing area, select the revision clouds to tag.
5 If desired, adjust the positions of the tags and their leader lines, as follows:
6 Use options on the Options Bar to remove the leader line (clear Leader) or to assign the tag to
For more information about applying a tag to an element, see
1016 | Chapter 15 Preparing Construction Documents
b Select segments of the revision cloud, and drag the endpoints to adjust its boundaries.
c On the Design Bar, click Finish Sketch.
a Right-click the cloud, and click Override Graphics in View
b Change the values for the Weight, Color, and Style of the cloud lines.
c Click OK.
These changes apply to all revision clouds in the project.
A project created using the default project template includes the Revision Tag or M_Revision
Tag family. To check whether another revision tag family is loaded, in the Project Browser, under
Families Annotation Symbols, look for the revision tag family name. To load a revision tag
family, see Loading Families
As you select each cloud, Revit Architecture displays a revision tag next to it. Numbers in the
tags reflect the revisions assigned to the clouds. (See
on page 1015.) On sheets, these tag numbers can differ. (See
or by Sheet on page 1011.)
a On the Design Bar, click Modify.
b Select a revision tag.
You may need to zoom in to see the controls for the revision tag.
c To reposition the tag, drag the blue arrows.
d To adjust the elbow in its leader line, drag the blue dot.
a different revision cloud (click Pick Host).
Object Styles.
Entering Revision Information
on page 352 for instructions.
By Element.
on page 1009.)
By Category.
Assigning a Revision to a Revision Cloud
Revision Cloud Numbering by Project
Tags on page 1064.
