Using keynotes
If you click Drafting menu
the keynote category. If the tag is not loaded in the project, you are prompted to load one.
The keynote family displays one or both of the values available from the keynote table. See
Settings
Using tags
If you click Drafting menu
category.
The default tag displays the value stored for the Description parameter, if it is assigned.

Keynoting Settings

To access the Keynoting Settings dialog, click Settings menu
Keynote Table
Full Path Displays the entire path of the keynote file.
Saved Path Displays the file name of the keynote file that is loaded.
View Opens the Keynotes dialog. This dialog does not permit editing the keynote table.
Path Type
Absolute Identifies a specific folder located on your local PC or a network server. The path could be stored
in the Uniform Naming Convention (UNC) format such as \\servername\share\folder\keynote.txt.
Relative Finds the keynote file where the project file or central file is located. If the file is moved to a new
location, Revit Architecture expects to find the keynote file in this new folder location as well.
At Library Locations Finds the keynote file where the stand-alone installation or network deployment
specified.
Numbering Method
By keynote Determines the keynote value by the value stored in the keynote parameter or selected from
the keynote table. This value displays in the keynote as well as filling in the keynote parameter.
By sheet Numbers keynotes according to their order of creation.
A value for the keynote parameter is still stored if one has been chosen.
A Keynote Legend displays the Keynote Number according to the order it was created instead. No number
appears in the tag until the view bearing Keynote Tags is placed on a sheet view.

Keynote Workflow

The default keynoting data provided in Revit Architecture is based on the 1995 Construction Specification
Institute (CSI) Master format system, which uses 16 divisions to organize construction process and materials.
This is a widely used system in the United States. See
A more recent version of this system has not yet seen wide-spread adoption. This newer version is based
upon 50 divisions and was introduced in 2004. Support for this new format can be accomplished by adding
the additional divisions to the default keynote data files as needed. See
page 1063.
Keynote
on page 1059.
Tag
Material, Revit Architecture looks for a tag family assigned to
Material, Revit Architecture uses a tag family assigned to the material
Keynote File Versions
Keynoting.
on page 1064.
Adding Additional Categories
