2 To add a new revision, click Add.
3 In the revision row, for Numbering, select Numeric, Alphabetic, or None.
4 For Date, enter the date on which the revisions are made or will be sent for review.
5 For Description, enter the description of the revision to display in revision schedules on sheets.
6 If the revision has been issued, enter values for Issued to and Issued by, and then select Issued.
7 For Show, select one of the following values. (These values apply after you assign the revision
8 Click OK.

Merging Revisions

You can merge (combine) revisions into a single entry. For some projects, you may want to merge all revisions
from a particular stage of the project. All new revisions for the next project stage are then listed individually.
When you merge revisions, the target revision (the revision being merged to) remains. Information about
the revision being merged is lost.
NOTE You cannot delete revisions in the Sheet Issues/Revisions dialog, but you can merge them.
To merge revisions
1 In the project, click Settings menu
2 In the Sheet Issues/Revisions dialog, click the sequence number for the revision to merge with
1010 | Chapter 15 Preparing Construction Documents
The Sheet Issues/Revisions dialog displays.
NOTE For your first revision, edit the values for the existing (default) revision row.
See
Numbering for Revisions
See
Issuing a Revision
on page 1019.
to one or more clouds.)
None: Does not display the revision cloud and the revision tag in the drawing.
Tag: Displays the revision tag and draws the revision cloud, but does not display the cloud
in the drawing. (To move or edit the cloud in the drawing, move the cursor over the cloud
area to highlight and select the cloud.)
Cloud and Tag: Displays the revision cloud and the revision tag in the drawing. This option
is the default.
another.
on page 1013.
Revisions.
