2 In the Line Weights dialog, click the Model Line Weights tab, and then click Add.
3 In the Add Scale dialog, select a scale value, and click OK.
4 Click OK to close the Line Weights dialog.

Deleting Scales

1 Click Settings menu
2 In the Line Weights dialog, click the Model Line Weights tab, and then select the View Scale
3 Click Delete.
4 Click OK.

Line Patterns

You can specify the pattern for the line styles used in Revit Architecture. Several predefined line patterns
are provided with Revit Architecture, or you can create your own. Line patterns are a series of dashes or dots
alternating with blank spaces.

Creating a Line Pattern

1 Click Settings menu
2 In the Line Patterns dialog, click New.
3 In the Line Pattern Properties dialog, enter a name for the pattern.
4 Click in the value for Type, and select either a dash or a dot.
5 If you selected dash, click under Value, and enter a value. This is the length of the dash. Since
6 In the next row, select space for Type. Revit Architecture requires that you follow a dash or dot
7 Click under Value, and enter a value for the space.
8 Repeat the procedure until the pattern is complete.
9 Click OK.
10 Click OK.
The new line pattern is stored in the project only.

Editing a Line Pattern

1 Click Settings menu
2 In the Line Patterns dialog, select the line pattern you wish to modify, and click Edit.
3 Make any necessary changes.
4 Click OK.
Line Weights.
header.
Line Patterns.
dots are all drawn at 1.5 points, they do not require an associated value.
with a space.
In the Line Patterns dialog, the new line pattern displays in the list of available patterns.
Line Patterns.
