3 Click in the drawing area to specify the start point of the line.
4 Move the cursor and click to specify the end point of the line.

Sketching a Rectangle

1 On the Design Bar, select a tool that allows for a rectangle, such as Lines.
2 On the Options Bar:
3 Click in the drawing area to specify the first corner of the rectangle.
4 Move the cursor and click to specify the diagonal corner of the rectangle.

Sketching a Circle

1 On the Design Bar, select a tool that allows for a circle, such as Lines.
2 On the Options Bar:
NOTE If you specify a radius, the Offset option is overridden.
NOTE You can also use listening dimensions to specify the length of the line. See
on page 233.
a Click (Rectangle).
b Optionally, select Offset and specify a value.
c Optionally, select Radius and specify a value.
Specifying a radius creates fillets at the corners of the rectangle.
The following image shows a rectangle sketched without Radius selected and a rectangle
sketched with Radius selected.
NOTE If you specify a radius, the Offset option is overridden.
a Click (Circle).
b Optionally, select Offset and specify a value.
c Optionally, select Radius and specify a value. If you specify a radius, placing a circle in the
drawing area requires only 1 click.
Listening Dimensions
Sketching a Rectangle | 255
